Chinese Researchers Design Reusable Net-Membrane That Folds Itself Up for Multiple Space Debris Captures
Featured image: [Diagram of the hybrid net-membrane capture system showing deployment sequence; credit: Yu et al., Space: Science & Technology 2026]
A team of Chinese researchers has proposed a new approach to one of the most stubborn problems in orbital debris cleanup: the high cost of single-use capture systems. Their design, published in the journal Space: Science & Technology, uses shape-memory alloys embedded in a thin membrane that can deploy, capture a piece of debris, and then fold itself back up for reuse on the next target.
The concept addresses a fundamental economic barrier. During the RemoveDEBRIS mission in 2018, Airbus and the Surrey Space Centre demonstrated that orbital nets can successfully capture debris, but the net was a single-use system. Once fired, it could not be retracted or reused, meaning each piece of debris required its own dedicated mission at enormous cost.
The new Chinese design, developed by researchers Shuangqing Yu, Jinguo Liu, and Pengyuan Zhao from the Chinese Academy of Sciences and the University of Electronic Science and Technology of China, embeds shape-memory alloy wires into a multi-layer flexible membrane just 10 microns thick : roughly the thickness of plastic wrap.
How it works
The capture sequence begins when the chaser satellite identifies a piece of debris and flies alongside it. Four projectiles : the paper calls them “mass bullets” : are fired at a 30-degree angle, each connected by a tether to a corner of the folded membrane. As the tethers pull tight, the multi-layer membrane unfurls and spreads out to envelop the debris.
On contact, the shape-memory alloy wires maintain the membrane’s wrapped shape, holding the debris securely. The chaser satellite then drags the captured debris via tether to a safe re-entry trajectory where it burns up in the atmosphere.
The key innovation comes after release: when a current is applied, the shape-memory wires return to their pre-set folded shape, pulling the membrane back into its storage container. The chaser can then proceed to the next target.
The membrane contains four layers: an electronics layer for command and control, a battery layer for onboard power, the shape-memory alloy wires for deployment and retraction, and a metal net layer for structural strength.
Simulation results
The study is purely numerical at this stage : technology readiness level 1-2, meaning the concept has been validated through dynamic modeling but no physical prototype or orbital test has been conducted. Simulations using the Multiparticle Method identified 30 degrees as the optimal deployment angle from the chaser, generating 3,374 newtons of force at 2 meters of deployment distance.
The system is designed for small to medium debris of various shapes, including spinning and irregular objects. It does not require the target to have docking interfaces or be cooperative : a major advantage over robotic arm approaches.
The researchers acknowledge significant limitations: the membrane must withstand large forces at only 10 microns thickness, the simulation omitted solar radiation pressure and atmospheric drag, and shape-memory alloy behavior at scale under thermal cycling in space has not been fully characterized.
The bigger picture
The economics of orbital debris removal have long been the field’s Achilles’ heel. NASA’s cost-benefit analysis shows that removing the 50 most statistically concerning large debris objects provides roughly $3 billion in risk-reduction benefit. But with roughly 40,000 cataloged objects in orbit and growing congestion from megaconstellations, per-piece removal costs must drop substantially for active debris removal to become viable.
The shape-memory membrane concept is years to decades from orbital deployment, but it opens a design path toward a future where a single chaser satellite could handle multiple pieces of debris on one mission. Other Chinese groups are pursuing complementary approaches; a team at Tianjin University recently developed a tentacle-like continuum robotic arm using superelastic nickel-titanium alloy for fine debris capture.
